Excellent discussion occurring on the #bitcoin-dev IRC channel (see channel log) regarding GPUs:

m: GPUs have plateau’d at 300W over the past 3 years

m: despite constant improvement of the perf/W

m: 300W is the max authorized by the PCIe specs for double-width cards

s: every watt has to be cooled too

l: so cant they use two 8 pins?

m: 75W from the slot, 75W from the 6-pin power connector, and 150W from the 8-pin one

s: wow, 75W from the PCIe slot?

m: electrically speaking they could, but they would be violating the specs

m: same thing for CPUs. they have plateau’d at ~130W because that’s 5.4 Amp on each wire of the 4-pin ATX12V connector which is dedicated to the CPU.

m: You can do up to 6, 7 Amps without the wires heating too much but it requires 16 gauge which most PSUs don’t have

Written on 13 Jan 2011.
